4-Channel Rack-Mount SATSIM

2-Channel Bench-Top SATSIM

1-Channel Bench-Top SATSIM


UHF BENCH-TOP & RACK-MOUNT SATSIMS

For more than two decades, SmartSAT's UHF satellite simulators have set the standard in test and measurement for government and prime contractor labs worldwide. Selected by DISA as the "gold SATSIM" for UHF SATCOM testing and embedded in the Joint Interoperability Test Command (JITC) certification facility, SmartSAT's SATSIMs are used to evaluate and certify all UHF SATCOM radios prior to deployment and transmission over U.S. satellites.
Easy to use and incredibly reliable, SmartSAT's family of SATSIMS are designed for years of 24/7 operation. Available in one-channel,  two-channel, four-channel and briefcase models.

•  accurately simulates satellite characteristics
•  selectable external or internal reference
•  fully controllable signal and noise levels
•  fully programmable propagation time delay
•  internal white noise generator
•  enhanced remote PC operation
•  intuitive touch-screen display
•  Legacy DAMA DC Mode CCOW and other options available

BRIEFCASE SATSIM

Just like its big brother, SmartSAT's Briefcase SATSIM features all the capability of a personal satellite channel but with the added benefit of complete portability. Equipped with a three-hour battery, removable touch-screen display, and onboard accessories, SmartSAT's Briefcase SATSIM is ideal for on-the-move SATCOM testing, including flight lines, shore-to-ship platforms and mobile SATCOM sites.

•  three-hour battery operation
•  external calibration
•  ruggedized case

Combiner Attenuator Test Set (CATS)


COMBINER ATTENUATOR TEST SET (CATS)

CATS  is a consolidated RF signal combiner/splitter attenuator system that brings order and efficiency to the RF test environment. Designed to simulate conditions found in UHF SATCOM over-the-air RF transmission and reception, the CATS is ideal for testing environments that require networked radios and for training with multiple, simultaneous users.

•  accepts up to six, simultaneous, 100 watt UHF uplink transmitter inputs
•  provides programmable signal level control by channel
•  combines downlink signals into a single RF environment
•  allows for the insertion of noise from an internal broadband noise generator
•  allows up to eight receivers to connect simultaneously via an eight-way downlink splitter

Narda-MITEQ introduces its expanded Frequency LCDRO Series Free Running Oscillator

The Narda-MITEQ LCDRO is a free running, low cost DRO that is used in many microwave radar and radio frequency applications for both commercial and military. With this new device, we have increased the upper frequency range output from 18 to 26 GHz. [Read more]

Low Noise Amplifier Series (from 100 MHz to 40 GHz)

Narda-MITEQ offers their latest series of low noise amplifiers with frequency ranges from 100 MHz to 40 GHz. These high performance, low cost LNAs are designed to offer customers the same high performance that the industry expects from Narda-MITEQ, while also providing reduced lead times. [Read More]

Narda-MITEQ Introduces New SBL Series of Fiber Optic Link Components

Narda-MITEQ announced the release of the new SBL Series of fiber optic link components. This continues the company’s tradition of supplying high performance "plug & play" fiber optic link components for linear and some digital applications. [Read more]

New High-Spectral Purity Synthesizers series SLS2

Narda-MITEQ announces the newest and smallest high-performance cost effective line of synthesizers SLS2. The SLS2 operates from 0.010 to 15 GHz in bands and 19 GHz in extended bands (with the capability of covering Octave bands) with the option of doubling frequency by using an external multiplier. [Read more]

Berkeley Nucleonics Corporation

Berkeley Nucleonics Academy is currently offering a Free RF Bootcamp (Limited Time Offer)
Register with your Email / Click “Add Coupon” and enter Coupon Code – BRENNAN


Watch a tutorial on BNC's offerings to R&D in Quantum Computing

Model 7000 Phase Noise Test Systems
From 1 MHz to 7 GHz, 26 GHz and 40 GHz

BNC’s Phase Noise Analyzers keep getting better and better! Real-time Phase Noise Test Systems are designed to provide the most accurate phase noise data possible and are customized to fit your specific performance and application needs, while maintaining state of the art data accuracy and verification. Compare performance and price to Keysight’s 5052 and you won’t be disappointed!  Even more, BNC provides FREE lifetime Tech Support!

Model 865-M | 0.01 to 40 GHz Wideband Low Noise Synthesizer

Model 865 | 100 kHz up to 40 GHz RF / Microwave Signal Generator

Model 865 comprises a set of the highest performance microwave signal generators from 100 kHz up to 40 GHz. Unrivaled signal purity in combination with fast switching and high output power make these models suitable for a wide variety of applications and the most advanced measurement tasks. READ MORE


Model 845 RF / Microwave Signal Generator (100 kHz to 26.5 GHz)

Model 835 | 9 kHz to 4 GHz or 6 GHz Microwave/RF Signal Generator

Model 835 is a low-noise, fast-switching analog RF signal generator that covers a frequency range from 9 kHz up to 6.1 GHz. It's a compact and portable, cost-effective alternative to other traditional and expensive RF Signal Generators! READ MORE


Model 855B | 300 kHz up to 40 GHz (settable to 42 GHz)
Multi-Channel RF / Microwave Signal Generator

Model 855 is a phase coherent, multi-output, fast switching and low phase noise signal generator with a frequency range from 300 kHz to 6.2, 12.5, 20.0 or 40 GHz. The 855 is ideally suited for a variety of applications where good signal quality and a wide, accurate output power range are required. Excellent phase noise is combined with spurious and harmonic rejection. READ MORE

• High-Q/Low ESR Capacitors are available in multiple case sizes, dielectrics and various terminations, which include ROHS compliant and Non-Magnetic finishes.

• Hi Q/Low ESR Design Kits: With over 40 kits available in stock, in 0201, 0402, 0505, 0603, 0805 and 1111 case sizes.

• Passive Plus, Inc. (PPI) has developed a series of Broadband Capacitors; the 01005BB104 broadband capacitors (the smallest on the market!), 0201BB103, 0201BB104, 0402BB103, 0402BB104 and the 0805BB.  For Optoelectronics / high-speed data, ROSA/TOSA (Transmit / Receive optical subassemblies), SONETS (Synchronous Optical Networks), Broadband test equipment, Broadband microwave and millimeter wave amplifiers and oscillators.

• PPI offers inventory programs for our customers, which allocates inventory and guarantee that parts are on the shelf and available to be shipped on demand

• The PPI Engineering Staff is available to support your technical and design needs, review and discuss technical data and circuit models, and make product recommendations.

OUR CUSTOMERS
ACS Test Labs, Adtran, Alliant Techsystems, Arris Interactive, BAE, Boeing, Cisco, Comtech, DRS, Eglin AFB, EMS, GTRI, Harris Corporation, Itron Electricity Metering, Lockheed Martin, Marshall Space Flight Center, MC Assembly & Test, Mnemonics, Motorola, MTRON-PTI, NASA, NSWC, Northrop Grumman, Oak Ridge National Labs, Panasonic Matsushita USA, Patrick AFB, Phase IV, Raytheon, Redstone Arsenal, Rockwell Collins, Sanmina-SCI, Scientific Research, Soneticom, Spectrum Microwave, SV Microwave, Sypris Test & Measurement, Tampa Microwave Labs, Time Domain Systems, Trak Microwave, TriQuint, Viasat, Warner Robins AFB, xG Technology, XM Satellite Radio and many more!
